Description

Jacket works in the Inverse Architecture (IA) and is designed for tracking people in warehouses, assembly plants, construction sites and similar environment.

The recommended configurations for Jacket is IA in 915/868MHz band with 4-8Hz update rate and Real-Time Player enable and TDMA submaps turned on. The resulting latency is 1-2 seconds – for the best tracking quality.

Jacket includes Mini-RX and 2 additional external microphones to provide the best performance in challenging conditions with potential multiple obstructions.

Demos:

Precise tracking of Marvelmind Jacket in office environment with obstructions

Lead time – several days.

Distance to beacons

  • Reaches up to 25 meters

Location precision

  • ±20 cm – split triple microphone

Location update rate and latency

Inverse Architecture:

  • 4–8Hz. Can be set manually
  • Recommended – overlapping submaps in TDMA mode

Power supply and battery lifetime

Internal:

  • LiPol battery 750mAh
  • Battery lifetime totally depends on usage, map configurations, update rate. With 8Hz update rate => up to 30h

External:

  • microUSB – for charging

Description

Jacket works in the Inverse Architecture (IA) and is designed for tracking people in warehouses, assembly plants, construction sites and similar environment.

The recommended configurations for Jacket is IA in 915/868MHz band with 4-8Hz update rate and Real-Time Player enable and TDMA submaps turned on. The resulting latency is 1-2 seconds – for the best tracking quality.

Jacket includes Mini-RX and 2 additional external microphones to provide the best performance in challenging conditions with potential multiple obstructions.

Demos:

Precise tracking of Marvelmind Jacket in office environment with obstructions

Lead time – several days.

Additional information

Weight 0.025 kg
Dimensions 4.7 × 4.2 × 1.5 cm
